Unleash the full potential of your audio system with the BANDA AUDIOPARTS BD800X4 amplifier, a powerhouse designed to deliver exceptional sound clarity and volume. Boasting a robust 800W RMS output over four channels, this amplifier is engineered to perform, whether you're setting up a home theater or powering your car audio system. Crafted with precision in Brazil, the BD800X4 model is a testament to enduring quality and performance. This particular unit is not part of a custom bundle and has not been modified, ensuring that you receive the standard, high-quality product straight from the manufacturer, complete with the original packaging and reliability that BANDA AUDIOPARTS is known for.
Parameter 800.4
Maximum Power 14.4v @ 2 Ohms
4 x 250 WRMS
Maximum Power 14.4v @ 4 Ohms
4 x 170 WRMS
Maximum Power 14.4v Bridge @ 4 Ohms
2 x 500 WRMS
Maximum Power 12.6v @ 2 Ohms
4 x 200 WRMS
Maximum Power 12.6v @ 4 Ohms
4 x 130 WRMS
Maximum Power 12.6v Bridge @ 4 Ohms
2 x 400 WRMS
Efficiency @ 4 Ohms
84%
Efficiency @ 2 Ohms
78%
Input Voltage
9 – 15V
Input Impedance
22K Ohms
THD+N
0.10%
Input Sensitivity
280mV – 4V
Signal-to-Noise Ratio
88dB
Frequency Response (OFF Switch)
–
Frequency Response
5 to 22kHz (-3dBs)
HPF (High Pass Filter)
20 to 90Hz @ 12dBs/8° Linkwitz-Riley
LPF (Low Pass Filter)
90 to 20kHz @ 12dBs/8° Linkwitz-Riley
Recommended Fuse
50 A
Idle Current
1 A
Maximum Current (sine wave)
90 A
Maximum Current (musical signal)
50 A
Power Supply Cables (min. recommended)
10mm / 7 AWG
Output Cables (min. recommended)
2 x 1.5mm / 2 x 15 AWG
Weight (Kg)
1,2
Height (mm)
54
Width (mm)
209
Depth (mm)
243
